Speeding up your HQL

Using an object-relational-mapper (ORM) to persist your entities, manage their state and query subsets for lists or reports is a wide-spread practice and may speed up your development.

If not used correctly, it may introduce unexpected performance problems because of unefficient default queries and the overhead this mapping introduces as most of the time table rows are converted to domain objects. Often this results in many queries and the n+1 query problem.

Nevertheless, the benefits of using an ORM may outweigh the problems and most problems can be mitigated by features and a correct usage of the tool.

Today I want to present a performance problem we had using GORM/Hibernate and how we easily fixed it without major code restructuring or workarounds.

The Problem

We used a HQL-query to load quite a lot of entities which took about 3 seconds. This was acceptable for our customer. If the user however tried to narrow down the results using a filter loading a smaller amount of the same entities took over 1 minute. Obviously, this was totally unacceptable and counter-intuitive.

The Analysis

Further analysis revealed, that a particular part of the WHERE-clause was responsible for the observed slowdown:

FROM Report r
WHERE r.project.proposal.id = p.id

So we did filter the root entity Report on an entity called Proposal but needed to load an associated Project entity for all reports to consider. So even if we are just using entity-ids to filter the innocently looking path r.project.proposal.id leads to loading and mapping of hundreds of Project entities.

The Solution

In our example we can fortunately do a lot better without big changes to our domain model, the application code or the query.

The relevant part of the schema looks like below:

In the above schema we can see, that both, a Report and a Proposal are associated with a certain project. Remember, that in Hibernate your entities contain only the id of their one-to-one mapped sub-entities by default. This means that if we change the filter clause to

WHERE r.project.id = p.project.id

we skip loading and mapping of all the Project entities and only load the needed reports and proposals. Since they both contain the project id we can use that in our filter. This resulted in more than a 10x speedup with such a simple and non-invasive change.

General Takeaway

ORMs can be a great tool but it is very easy to shoot yourself into the foot. With enough care you can achieve both simple code and good performance but you may run into non-obvious problems every now and then.

Understanding, identifying and fixing the N+1 query problem

One of the most common performance pitfalls for applications accessing data from databases is the so-called “N+1 query problem”, or sometimes also called the “N+1 selects problem”. It is the first thing you should look for when an application has performance issues related to database access. It is especially easy to run into with object-relational mappers (ORMs).

The problem

The problem typically arises when your entity-relationship model has a 1:n or n:m association. It exists when application code executes one query to get objects of one entity and then executes another query for each of these objects to get the objects of an associated entity. An example would be a blog application that executes one query to fetch all authors whose names start with the letter ‘B’, and then another query for each of these authors to fetch their articles. In pseudocode:

# The 1 query
authors = sql("SELECT * FROM author WHERE name LIKE 'B%'");

# The N queries
articles = []
FOR EACH author IN authors:
    articles += sql("SELECT * FROM article WHERE author_id=:aid", aid: author.id)

The first query is the “1” in “N+1”, the following queries in the loop are the “N”.

Of course, to anybody who knows SQL this is a very naive way to get the desired result. However, OR mappers often seduce their users into writing inefficient database access code by hiding the SQL queries and allowing their users to reach for the normal tools of their favorite programming language like loops or collection operations such as map. A lot of popular web application frameworks come along with OR mappers: Rails with Active Record, Grails with GORM (Hibernate based), Laravel with Eloquent.

How to detect

The easiest way to detect the problem in an application is to log the database queries. Virtually all ORMs have a configuration option to enable query logging.

For Grails/GORM the logging can be enabled per data source in the application.yml config file:

dataSource:
    logSql: true
    formatSql: true

For Rails/ActiveRecord query logging is automatically enabled in the development environment. Since Grails 5.2 the Verbose Query Logs format is enabled by default, which you had to explicitly enable in earlier versions.

For Laravel/Eloquent you can enable and access the query log with these two methods/functions:

DB::connection()->enableQueryLog();
DB::getQueryLog();

Once query logging is enabled you will quickly see if the same query is executed over and over again, usually indicating the presence of the N+1 problem.

How to fix

The goal is to replace the N+1 queries with a single query. In SQL this means joining. The example above would be written as a single query:

SELECT article.*
FROM article
JOIN author
  ON article.author_id=author.id
WHERE author.name LIKE 'B%'

The query interface of ORMs usually allows you to write joins as well. Here the example in ActiveRecord:

Article.joins(:authors).where("authors.name LIKE ?", "B%")

Another option when using ORMs is to enable eager loading for associations. In GORM this can be enabled via the fetchMode static property:

class Author {
    static hasMany = [articles: Article]
    static fetchMode = [articles: 'eager']
}

REST APIs

The problem isn’t limited to SQL databases and SQL queries. For REST APIs it’s the “N+1 requests problem”, describing the situation where a client application has to call the server N+1 times to fetch one collection resource + N child resources. Here the REST-API has to be extended or modified to serve the client’s use cases with a single request. Another option is to offer a GraphQL API instead of a REST API. GraphQL is a query language for HTTP APIs that allows complex queries, so the client application can specify exactly what resources it needs with in a single request.

Object slicing with Grails and GORM

Some may know the problem called object slicing when passing or assigning polymorphic objects by value in C++. The issue is not limited to C++ as we experienced recently in one of our web application based on Grails. If you are curious just stay awhile and listen…

Our setting

Some of our domain entities use inheritance and their containing entities determine what to do using some properties. You may call that bad design but for now let us take it as it is and show some code to clarify the situation:

@Entity
class Container {
  private A a

  def doSomething() {
    if (hasActuallyB()) {
      return a.bMethod()
    }
    return a.something()
  }
}

@Entity
class A {

  def something() {
    return 'Something A does'
  }
}

@Entity
class B extends A {

  def bMethod() {
    return 'Something only B can do'
  }
}

class ContainerController {

  def save = {
    new Container(b: new B()).save()
  }

  def show = {
    def container = Container.get(params.id)
    [result: container.doSomething()]
  }
}

Such code worked for us without problems in until we upgraded to Grails 3. Suddenly we got exceptions like:

2019-02-18 17:03:43.370 ERROR --- [nio-8080-exec-1] o.g.web.errors.GrailsExceptionResolver   : MissingMethodException occurred when processing request: [GET] /container/show
No signature of method: A.bMethod() is applicable for argument types: () values: []. Stacktrace follows:

Caused by: groovy.lang.MissingMethodException: No signature of method: A.bMethod() is applicable for argument types: () values: []
at Container.doSomething(Container.groovy:123)

Debugging showed our assumptions and checks were still true and the Container member was saved correctly as a B. Still the groovy method call using duck typing did not work…

What is happening here?

Since the domain entities are persistent objects mapped by GORM and (in our case) Hibernate they do not always behave like your average POGO (plain old groovy object). They may in reality be Javassist proxy instances when fetched from the database. These proxies are set up to respond to the declared type and not the actual type of the member! Clearly, an A does not respond to the bMethod().

A workaround

Ok, the class hierarchy is not that great but we cannot rewrite everything. So what now?

Fortunately there is a workaround: You can explicitly unwrap the proxy object using GrailsHibernateUtil.unwrapIfProxy() and you have a real instance of B and your groovy duck typing and polymorphic calls work as expected again.

GORM-Performance with Collections

The other day I was looking to improve the performance of specific parts of our Grails application. I quickly found the typical bottleneck in database centric Grails apps: Too many queries were executed because GORM hides away database queries by its built-in persistence methods for domain objects and the extremely nice dynamic finders. In search for improvements and places to use GORM/Hibernate caching I stumbled upon a very good and helpful presentation on GORM-performance in general and especially collection usage. Burt Beckwith presents some common problems and good patterns to overcome them in his SpringOne 2GX talk. I highly recommend having a thorough look at his presentation.

Nevertheless, I want to summarize his bottom line here: GORM does provide a nice abstraction from relational databases but this abstraction is leaky at times. So you have to know exactly how the stuff in your domain classes is mapped. Be especially careful it collections tend to become “large” because performance will suffer extremely. We already observed a significant performance degradation for some dozen elements; your mileage may vary. For many simple modifications on a collection all its elements have to be loaded from the database!
Instead of using hasMany/belongsTo just add a back reference to the domain object your object belongs to. With the collection you lose cascading delete and some GORM functionality but you can still use dynamic finders and put the functionality to manage associations yourself into respective classes. This may be a large gain in specific cases!

The Grails performance switch: flush.mode=commit

Some default configuration options of Grails are not optimal for all projects.

— Disclaimer —
This optimization requires more manual work and is error prone but isn’t this with most (big) performance improvements?
For it to really work you have to structure your code accordingly and flush explicitly.

Recently in our performance measurements of a medium sized Grails project we noticed a strange behavior: every time we executed the same query the time it took increased. It started with 40ms and every time it took 1 ms more. The query was simple like Child.findAllByParent(parent)
The first thought: indexes! We looked at the database (a postgresql db) and we had indexes on the parent column.
Next: maybe the session cache got too large. But session.flush() and session.clear() did not solve that problem.
Another post suggested using a HQL query. Changing to

Child.executeQuery("select new Child(c.name, c.parent) from Child c where parent=:parent", [parent: parent])

had no effect.
Finally after countless more attempts we tried:

session.setFlushMode(FlushMode.COMMIT)

And not even the query executed in constant time it was also 10x faster?!
Hmmm…why?
The default flush mode in Grails is set to AUTO
Which means that before every query made the session is flushed. Every query regardless of the classes effected. The problem is known for hibernate but after 4! years it is still unresolved.
So my question here is: why did Grails chose AUTO as default?
