Imagine you want to use a C++ service from contained in a .dll file from a C# host application. I was using a C++ service performing some hardware orchestration from a C# WPF application for the UI. This service pushes back events to the UI in undetermined intervals. Let’s write a small C++ service like that real quick:

#include <thread>
#include <string>

using StringAction = void(__stdcall*)(char const*);

void Report(StringAction onMessage)
{
  for (int i = 0; i < 10; ++i)
  {
    onMessage(std::to_string(i).c_str());
    std::this_thread::sleep_for(std::chrono::seconds(1));
  }
}

static std::thread thread;

extern "C"
{
  __declspec(dllexport) void __stdcall Start(StringAction onMessage)
  {
    thread = std::thread([onMessage] {Report(onMessage);});
  }

  __declspec(dllexport) void __stdcall Join()
  {
    thread.join();
  }
}

Compile & link this as a .dll that we’ll call Library.dll for now. Catchy, no?

Now we write a small helper class in C# to access our nice service:

class LibraryLoader
{
  public delegate void StringAction(string message);

  [DllImport("Library.dll", CallingConvention = CallingConvention.StdCall)]
  private static extern void Start(StringAction onMessage);

  [DllImport("Library.dll", CallingConvention = CallingConvention.StdCall)]
  public static extern void Join();

  public static void StartWithAction(Action<string> action)
  {
    Start(x => action(x));
  }
}

Now we can use our service from C#:

LibraryLoader.StartWithAction(x => Console.WriteLine(x));
// Do other things while we wait for the service to do its thing...
LibraryLoader.Join();

If this does not work for you, make sure the C# application can find the C++ Library.dll, as VS does not help you with this. The easiest way to do this, is to copy the dll into the same folder as the C# application files. When you’re starting from VS 2019, that is likely something like bin\Debug\net5.0. You could also adapt the PATH environment variable to include the target directory of your Library.dll.

If you’re getting a BadImageFormatException, make sure the C# application is compiled for the same Platform target as the C++ application. By default, VS builds C++ for “x86”, while it builds C# projects for “Any CPU”. You can change this to x86 in the project settings under Build/Platform target.

Now if this is all you’re doing, the application will probably work fine and report its mysterious number sequence flawlessly. But if you do other things, e.g. something that triggers garbage collection, like this:

LibraryLoader.StartWithAction(x => Console.WriteLine(x));
Thread.Sleep(2000);
GC.Collect();
LibraryLoader.Join();

The application will crash with a very ominous ExecutionEngineException after 2 seconds. In a more realistic environment, e.g. my WPF application, this happened seemingly at random.

Now why is this? The Action<string> we registered to print to the console gets garbage collected, because there is nothing in the managed environment keeping it alive. It exists only as a dependency to the function pointer in C++ land. When C++ wants to message something, it calls into nirvana. Not good. So let’s just store it, to keep it alive:

static StringAction messageDelegate;
public static void StartWithAction(Action<string> action)
{
  messageDelegate = x => action(x);
  Start(messageDelegate);
}

Now the delegate is kept alive in the static variable, thereby matching the lifetime of the C++ equivalent, and the crash is gone. And there you have it, long-lasting callbacks from C++ to C#.
